microDRCE – Digital Radar Central Electronics for MicroSAR

Space Segment
  • Payload
Cycle
  • Product Development
The proposed activity identified as microDRCE, is an advanced solution for the digital section of SAR electronic Subsystem, suitable for microSAR payload and developed at board level for a lightweight concept microsatellite solution. microDRCE enhances the TAS-I SAR Micro Satellite Constellation (SMSC) product, an end-to-end system with microSAR instrument able to implement all the standard operative modes.
Objectives of the Product

Nowadays, most of the applications that customers need require high responsiveness capability and extended areas monitoring. These needs can be satisfied by deploying a SAR satellite constellation system with multi launch capability to optimise both the launch strategy and costs. Therefore, it is key to evolve the present radar technologies to improve both the SAR instrument flexibility, in line with the customers’ request, and its compactness for microsatellite configuration for the constellation purpose. The relevant TAS-I product is the SAR Micro Satellite Constellation (SMSC).


The intention is to develop a micro SAR instrument which implements all the standard operative modes (Stripmap, Spotlight, ScanSAR) to operate on a micro platform; for such reason an advanced and highly flexible digital SAR electronic subsystem section is a key feature. The innovative SAR instrument is conceived with an electronic digital section developed at board level to be compatible with the lightweight microsatellite solution concept, targeting a satellite product for the deployment of constellations with a variable number of satellites.


Customers and their Needs

Typical Customer needs are summarised in the following table, highlighting for each Need the “Pain” and “Gain” offered by the SMSC product.


Targeted customer/users countries

Institutional and commercial entities distributed worldwide which intend to improve their national services and space capabilities.


Product description

The microDRCE is a key element of the digital section of the SAR electronic subsystem of the SMSC product, an End-to-End Earth Observation System consisting of:

  • Space Segment organised in constellation with medium or large number of SAR satellites with a mass <200kg
  • Radar Ground Segment composed of the Core Ground Segment and the Image Analytics Segment

The key features of the SMSC product are:

  • High responsiveness capability
  • Regional or global access capability, able to operate in inclined or Sun-synchronous orbit
  • Satellite architecture optimised for a product perfectly suitable, in terms of mass and volume, to be easily deployed in large constellation
  • Fast orbital replacement thanks to the compatibility with several launchers
  • X-band multi-mode SAR Instrument (Spotlight, Stripmap and ScanSAR) based on an active planar phased array antenna relying on an innovative highly integrated architecture

The SAR Microsatellite constellation product is able to serve at the maximum extent all the emerging Space Services with “quasi real time” applications and high performances.

Added Value

Nowadays, most of the applications that the customers need, require high responsiveness capability and extended areas monitoring. The actual SAR Earth Observation systems mainly rely on high-end systems, that provide high image quality capability with poor temporal performance due to a reduced constellation size. On the other hand, in the last years, several emerging companies have deployed (or are in the process to deploy) large constellations of SAR microsatellites, providing commercial services which address specific fields of applications but do not cover all the customer needs. The new SMSC product is able to satisfy all the market needs coming from present and potential future customers.

The distinctive features of the SMSC product are:

  • High responsiveness capability
  • Regional or global access capability
  • Satellite architecture optimised for multi launch to be easily deployed in large constellation
  • Fast orbital replacement thanks to the compatibility with several launchers

X-band multi-mode SAR Instrument based on an active planar phased array antenna to cover all the customer needs.

Current Status

Kick-Off meeting held on April 12, 2023. Activities regarding Requirements Consolidation phase in progress. Requirement Review to be held on May 31, 2023.

Prime Contractor Company
Thales Alenia Space
Italy Flag Italy
Contractor Project Manager
Name
Vanessa Mastroddi
Address
Via Saccomuro 24, 00131 Roma, Italy
ESA Point of Contact
Name
Ricardo Pinto
